Aftermarket Products & Services for Pulp & Paper Plants

Riley Power logo

PEOPLE, AVAILABILITY, AND QUALITY OF DELIVERABLES

MILL SYSTEMS

Paper mill equipment: New pulverizers, pulverizer system upgrades (requiring guarantees), addition of classifiers, hydraulic systems, etc.

BURNER RETROFITS

Riley Power’s extensive offering of low NOx burners are designed to work with any OEM’s wall-fired or corner-fired steam generator, for both new construction, as well as for existing units. All burners can be designed to operate with or without overfire air, as well as other low NOx technologies, such as SCR and SNCR.

Replacement of wall or corner-fired burners possibly accompanied by new emission guarantees and/or boiler performance guarantees. Partial replacements with incremental emissions reductions.

PRESSURE PART RETROFITS

Redesign of boiler for performance improvements including guarantees. Replacements “in-kind” utilizing off-shore fabrication with or without guarantees.

TURNKEY

Burners and/or pressure parts, quoted with TEiC (open shop) or with union labor (subcontract with preferred installation contractors).

FUEL CONVERSIONS

Provide design and supply or full EPC fuel conversion including coal to gas and coal to oil.

BURNER PARTS

Riley Power’s in-house engineering capabilities allow for fast-drawing creation on components requiring repair or replacement. Once completed these components are typically fabricated or repaired in-house while the burners are in process of being rebuilt. OEM burners that we service:

  • GE / ALSTOM Corner T-fired Burner – Coal Nozzle Assemblies
  • Foster Wheeler Coal Burners
  • B&W XCL Burner Nozzles
COMPONENT REBUILDS

Components Riley Power rebuilds at our Tyler, Texas locations:

  • Ball Tube Mill Gearbox
  • Alstom / GE Gearboxes, Journal Assemblies
  • Raymond (Arvos) Roller & Gearbox Assemblies
  • Hitachi VS Type Roll Wheel Assemblies
  • B & W MPS Series Roller & Gearbox Assemblies
  • Foster Wheeler MBF Roller Assemblies
GRINDING ROLL WELD OVERLAY SERVICES

Process:

  • Prior to applying weld, visual & dye penetrant inspections are done to ensure any existing cracks or flaws have been identified.
  • Riley power will then restore to OEM diameter or specification.
  • No filler material is used in any part of the process.
  • Riley Power has a variety of competitively priced weld wires available, should our premium wire not be required depending on application.
NEW PULVERIZER PARTS

We provide parts for the following OEMs:

  • Alstom / GE
  • Foster Wheeler
  • IHI
  • Hitachi
FIELD & TECHNICAL SERVICES

Inspections

Riley Power provides inspections of boiler design, auxillaries, instrumention and controls, fuel firing systems and stress analysis complemented with qualified field service personnel. We provide detailed inspection reports in a meeting held with your plant personnel to review the findings. A copy of the team’s field notes is left to assist plant to implement immediate or short-term repairs as required. A formal final report is issued containing finding, conclusions and recommendations.

Drone Inspections

Condition Assessments

Riley Power provides customized condition assessments of boiler components. We determine the current condition of your boiler, pressure part components and/or associated auxiliaries and provide results that can be used for planning scheduled outages and to help avoid forced outages. Our assessments are reliable and accurate and provide better control over operating and maintenance budgets.

Performance & Emission Testing

Riley Power provides a variety of testing services and engineering studies to assess your unit’s performance. Our testing services include: baseline performance assessment, efficiency and heat rate improvement, fuel system balancing and combustion optimization and cycling operation and equipment turndown capability studies.

ENGINEERING STUDIES
  • Structural Steel Design
  • Balance Draft Conversions
  • Emissions Reductions
  • Boiler Capacity Upgrades
  • Performance Optimization
  • Life Assessment
  • Computational Fluid Dynamics
  • Boiler Technology
  • Combustion Technology
  • Mechanical Design
  • Fuel Conversion
TRAINING

Training opportunities include:

  • New Systems Training
  • System Operation Training
  • Maintenance Training
METALLURGICAL LABRATORY

For more than six decades, Riley Power Inc. (RPI) has provided expert boiler metallurgical analyses. Our metallurgical laboratory is capable of conducting extensive analyses services, including destructive and nondestructive condition assessments, failure analysis, finite element analysis, quality control and any other materials related concerns.

Boiler Tube Company of America

Original Equipment Manufacturer Serving Pressure Parts Needs for Over One Century

FABRICATED PRODUCTS

Superheaters

Superheater materials, configuration, and design vary significantly. Some of these materials may require heat treatment to ensure prolonged life. BTA can assist with up-grading your superheater components. Superheaters often have tight radius bends. BTA has specific hot-forming procedures to assure acceptable bend geometry and material mechanical characteristics.

Headers

BTA can supply you with all your replacement header needs: machined, welded, tested, and stress relieved, if required. During the fabrication process, the pressure parts produced are under the strictest surveillance of BTA’s Quality Control Department to ensure compliance with the ASME codes.

Waterwalls

Waterwall materials, configuration, and design vary greatly depending on the style of boiler. Most waterwalls utilize a membrane panel construction. BTA uses a fully automatic, submerged arc process to weld both sides of the panel.Bent panels are typically fabricated on a panel bender to assure correct alignment of tubes.

Economizers

With extensive experience, the latest technology, surface materials and configurations, BTA has complete economizer design capabilities. We begin with the optimum surface for the application. We consult with you on your type of fuel, heat source, flue gas characteristics, operating hours, load variation, available draft, fouling, pluggage, sootblower requirements, gas velocity, and temperatures to provide you  with the optimum solution.

WELD OVERLAY

Boiler Tube Company of America is a leader in providing boiler replacement pressure part components that improve unit performance by extending component life. Primary to achieving extended life is the use of Boiler Tube Company of America’s spiral clad tubing that utilizes state-of-the-art welding technology. Boiler Tube Company of America has developed a Hot Wire Gas Tungsten Arc welding process using Wave Pulse Technology (patented). Use of the Wave Pulse Technology with automatic hot wire TIG utilizing a fully integrated robotic microprocessor controlled system results in reduced weld metal dilution chemistry throughout the thickness of the overlay and favorable fusion properties.

STRAIGHT TUBES
OTHER PRODUCTS
  • Burner Openings
  • Finned Economizer
  • Generating Tubes
  • Screen Tubes
Babcock Power Environmental logo

IMPROVE EFFICIENCY, OPERATION AND CONSUMPTION WITH THE GOAL OF REDUCING OPERATION & MAINTENANCE SPENDING

MIXERS TO IMPROVE PERFORMANCE

SCR Upgrades

It is as important to establish good distribution of flue gas flow, temperature, particulate, and NOx upstream of the ammonia injection system as it is to maintain ammonia distribution to the SCR. Optimizing distribution:

  • Reduces effects of unit firing & flow configurations
  • Provides homogenous flue gas and particulate mixing at the catalyst face
  • Maintains mixing at low load operation
  • Reduces the catalyst minimum operating temperature
  • Reduces number of NOx monitors
  • Reduces ABS formation
  • Improves air heater efficiency

DSI Upgrades

Coupling sorbent injection with Babcock Power mixing technology ensures full mixing in short section of ductwork across the operating load range improving removal and reducing sorbent consumption. BPE Delta DSI systems reduce the number of lances required by more than 50% compared to a traditional DSI system. Locating the DSI system upstream of the SCR provides additional benefits including:

  • Reducing catalyst minimum operating temperature
  • Increasing sorbent residence time and therefore reducing lime consumption
  • Reducing ABS scaling
  • Improving air heater efficiency
  • Reducing ammonia slip
  • Increasing catalyst life
  • Removing a fraction of HCl upstream of the WFGD system
BTA IMTEC Doors logo

EXPERTLY ENGINEERED DOOR SOLUTIONS FOR MAXIMUM SAFETY AND COST SAVINGS.

IMTEC FLEXISEAL ACCESS DOORS

Boiler Tube Company of America/Imtec has been manufacturing Access Doors for the power industry since 1984. We have over 20,000 units installed and have experience in all areas of the power plant from the boiler to the stack.

 The FLEXISEAL doors have one or more yokes with closing screws that act on center point(s) of the door. This flexes the door plate toward the interior and assures a tight seal with the gasket. When opening the door, special safety features in the latch and screw mechanism(s) will assure that the latch pin cannot be removed easily until the door plate with its gasket is safely retracted from the sealing surface on the frame plate, thereby revealing any dangerous internal pressure and also preventing damage to the gasket.

IMTEC BOILER DOOR WITH TUBE PANEL

Imtec’s boiler doors with matching tube panels are available with a max operating temperature of 2800 degrees. The boiler door must withstand high operating and excursion gas temperatures. Therefore, on boiler doors type BC the inner side of the door plate is equipped with high efficiency insulation supported by interior shelves and all contained in a protective Insulation pan which is protected by a 2” layer of castable refractory. For flexibility and heat expandability the pan is made with slots and in movable sections from heat resistant steel. When installed, this insulation pan must be closely surrounded by water wall tubes shaped in a fashion to match the conical shape of the insulation pan.

IMTEC CATALYST MODULE REMOVAL DOOR (LAYDOWN TYPE)

Imtec Catalyst doors are designed to minimize the time required to remove and reinstall your Catalyst Modules. In most cases we can reduce the time needed to remove and reinstall casing/doors by 75% thus resulting in a very short payback period.

We have over 500 numerous installations of our doors in various plants throughout the U.S. A reference list is available upon request.

IMTEC CATALYST MODULE REMOVAL DOOR (SWING TYPE)

Imtec Catalyst doors are designed to minimize the time required to remove and reinstall your Catalyst Modules. In most cases we can reduce the time needed to remove and reinstall casing/doors by 75% thus resulting in a very short payback period. We offer doors that will work regardless of the type of removal you are performing (tracks, monorail or carts). Our patented door also allows for it to be raised above the floor level to swing out of the way.

We have over 500 installations of our doors in various plants throughout the U.S. A reference list is available upon request.

IMTEC DUCT DOORS (SINGLE & DOUBLE)

Imtec’s duct doors are available in three different styles: uninsulated, insulated and double doors with various operating temperatures from 400 degrees to 1000 degrees.

IMTEC INSULATED SINGLE DOOR WITHOUT TUBE PANEL (MAX OPERATING 1800)

Imtec’s boiler doors without tube panels are available with a max operating temperature of 1800 degrees. The boiler door must withstand high operating and excursion gas temperatures. Therefore, on boiler doors type BM the inner side of the door plate is equipped with high efficiency insulation supported by interior shelves and all contained in a protective insulation pan which, for flexibility and heat expandability, is made with slots and in movable sections from heat resistant steel. When installed, this insulation pan must be closely surrounded by either refractory, a steel casing or water wall tubes shaped in a fashion to match the conical shape of the insulation pan.

IMTEC PENTHOUSE DOOR

Imtec’s penthouse doors are available in three standard sizes. With operating temperatures of 1000 degrees, these large penthouse doors permit quick access and rapid cooling of the boiler penthouse at forced outages.

IMTEC ROOF DOOR

Imtec’s roof doors are available in two different styles, with operating temperatures from 400 degrees to 1000 degrees.

Thermal Engineering International (TEi) logo

DESIGN SOLUTIONS FOR ALL YOUR HEAT TRANSFER EQUIPMENT

PARTS
  • Anode
  • Basket Tips
  • Baffle Plates
  • Channel Assemblies/Covers
  • Connectors
  • Demister
  • Diaphragm Plates
  • Expansion Joints
  • Extrusion Seals / Sealant
  • Gaskets
  • Kits – Vaccum System
  • Lantern Ring
  • Manway Assemblies/Covers
  • Manway Handling Device
  • Orifices
  • O-Rings
  • Packing
  • Partition Covers/Bolting Ring
  • Pressure Gauges
  • Rapture Discs
  • Relief Valves
  • Small Heat Exchanger
  • Spray Nozzles
  • Studs, Nuts, Bolts, Washers
  • Temperature Gauges
  • Thermocouples
  • Thermowells
  • Tube Bundle Replacement
  • Tube Expander Tool Set
  • Tube Plugs
  • Tubesheet (Stationary/Floating)
  • Tube Stakes
  • Torus Ring
  • U-Tubes
ENGINEERING CONSULTING
  • Performance analysis
  • Model testing
  • FEA analysis
  • Heater train studies
  • Vibration analysis
  • Repair vs. replace planning
  • Equipment modifications
  • Training seminars
TEiC Heat Exchanger Services logo

Extend the Life of Your Asset

TUBE CLEANING
  • Projectile
  • Rotary
TUBE TESTING
  • Eddycurrent
  • Pneumatic Vacuum
  • Hydro & Air
  • Shell
TUBE STABILIZERS
  • Cable design
  • Solid rod design
TUBE PLUGGING
  • Mechanical
  • Explosive
TROUBLESHOOTING

Troubleshooting and repair of Condensers, Feedwater heaters or any type of Shell and Tube Heat Exchanger issues by trained and qualified personnel.

TUBE SAMPLES
  • Condenser
  • U-Tube
  • Feedwater Heaters
  • Lube Oil Coolers
TUBE SLEEVES
  • Condenser
  • U-Tube Feedwater Heater
  • Lube Oil Cooler
INSTALLATIONS
  • Condenser
  • U-Tube Feedwater Heater
  • Lube Oil Cooler
REPAIRS & MODIFICATIONS
  • Condenser
  • U-Tube Feedwater Heater
  • Lube Oil Cooler
teic construction services logo

TOP PEOPLE, REGIONAL LOCATIONS, WE DELIVER

CONSTRUCTION SERVICES

TEIC Construction Services leads the industry with more than 20 years experience in providing direct-hire, on-site construction services for the installation, repair, alteration and maintenance of boilers and boiler-related equipment nationally. Our services include:

• Gas Conversions
• Ash Dewatering Systems
• Auxiliary Boiler Installation
• Environmental Control Systems

OUTAGE SERVICES

Focused on doing outage work the right way, TEiC provides open shop direct-hire construction services for new and existing plants. TEiC provides on-site construction services for the installation, alteration, repair, or maintenance of any OEM’s boiler and boiler related equipment, including but not limited to pressure parts, firing systems, air heaters, fans, feedwater heaters, condensers, piping, and ductwork.

With a proven track record of safety, on-time completion, and customer satisfaction, you can count on TEiC to meet all your requirements of new or existing installations.

Balance of Plant Services (BOP)

  • Structural Steel
  • Piping & Valves
  • Duct Work
  • Conveyors
